Seaweed Dryer Machine

Product Type :
Continuous Multi-layer Mesh Belt Dryer
Output :
200-3000kg/h
Drying Time :
0.5h-5h
Temperature :
40-120℃
Power Input :
23KW-150KW
Heat Source :
Coal,wood chips,natural gas,diesel,propane,electricity etc.
Customization :
Can be customized
Core Advantages :
Continuous automatic work/ Large output/ Dryer time short/ Flexible heat source selection
Share:
Production introduction

Seaweed dryer machine is a kind of continuous production drying equipment, the main heating way has electric heating, steam heating, and hot air heating. Its main working principle is to spread the material evenly in the network. The material is moved in the dryer by the operation of the machine, and the hot air draws out the water vapor of the material. so as to achieve the purpose of drying.

The operation temperature is 40-120 degree centigrade. And the dry cycle is 1-5 hours.

Product components

Seaweed dryer machine includes a heat source, feed conveyor, air intake system, discharge conveyor, electronic control system, and drying host.

Heat source selection of seaweed dryer machine:

Advantages of the seaweed dryer machine:

1. High capacity: The seaweed dryer machine has continuous automatic production, fast dehydration speed, short drying time, and high output.

2. High quality: Seaweed can be maintained full of shape, bright, color.

3. Clean and sanitation: The entire seaweed drying process is completed in a closed box, free from external pollution.

4. Intelligent and controllable: High degree of automation equipment, simple operation. Drying area, air pressure, air flow, drying temperature, and belt running speed can be adjust.

5. Wide usage: Can be used for material from any field.

6. Flexible heat source selection: Coal,wood chips,natural gas,diesel,propane,electricity etc.

7. Flexible mobility, simple or without installation.

Application of the seaweed dryer machine:

The mesh belt dryer machine is suitable for food series, vegetable series, fruit series, pharmaceutical series, agricultural and sideline products of large-scale continuous dehydration drying. It is an ideal choice for large enterprises to dry fruits, vegetables, flowers, leaves, meat, pet snacks, herbs, spices, nuts, seeds, and seafood.

Seaweed drying processing steps

1:Place the seaweed on the conveyor belt of the seaweed dryer machine. The seaweed is spread on the feeder by the homogenizing device on the conveyor belt.The stacking thickness of seaweed is 10-20CM.

2:After the seaweed enters the seaweed dryer machine, it runs in an "S" shape in the dryer. The transmission part of the seaweed dryer machine adopts a variable-frequency speed-regulating motor, which can control the internal operation time of the drying according to the difference of the water content of the seaweed.

3:The wind speed and wind pressure generated by the hot air blower make the hot air fully and evenly distributed inside the seaweed dryer machine. Because the lower pressure is greater than the upper pressure, the hot air naturally moves upward, passing through each layer of the mesh belt, plus the movement and rolling of the seaweed, Make the seaweed fully contact with the hot air, fully heat exchange, and improve the drying efficiency. The dried seaweed will drain through the last layer.


Technical Parameter
Continuous mesh belt dryer list
Model  Operation

temperature

Drying time Thickness of the material The size of motor Capacity Heat source Total power
BX-2*6M 40-120℃ 0.5-5h 50-200mm 6*2*2.5 200-400kg/h electricity 66.5kw
natural gas/propane 12.22kw
coal/wood chips 13.72kw
steam 11.22kw
BX-2*9M 9*2*2.5 500-800kg/h electricity 79.76kw
natural gas/propane 20.12kw
coal/wood chips 23.12kw
steam 16.62kw
BX-2*12M 12*2*2.5 1000-1500kg/h electricity 153.12kw
natural gas/propane 33.12kw
coal/wood chips 36.12kw
steam 25.62kw
The continuous drying machine can be equipped according to the user's requirement and the production demands.
